TC1000 controller kit for SurRon Ultra Bee

1.213,19 $

Price not including VAT

From our webshop to your doorstep in 5-7 days!

___________________

TC1000 controller has been developed to boost the performance of the SurRon Ultra Bee e-bikes. Get up to 17kW with Stock battery or 30kW with the aftermarket 72V battery.

Easy to install and configure with just a couple of clicks of the app.

Find out more…

SKU: N/A Category:

Description

INCLUDED IN THE PACKAGE:

-1x TC1000 Controller
-1x wire harness with special electronics
-1x aluminum heatsink (comes in 3 different colors: black, red or blue)
-screws and tools needed for installation
-4x stickers
-1x pack of silicone grease
-short instructions

SPECIFICATIONS:

-Field-oriented control (FOC)
-Supported batteries: up to 80V nominal 22S (92,4 V fully charged)
-Max Power: 50kW*
-Sensored (HALL Encoder) and sensorless control
-Max Battery Current: 700 A
-Max phase current: 1000 A*

*The maximum power you can achieve depends on the motor and battery you are using. The max PA depends on your motor.

-Efficiency up to 99%
-Working temperature: from -15 to 75 C°
-Bluetooth communication
-Pre-calibrated: Easy calibration through mobile app
-Overcurrent, overvoltage, undervoltage and overtemperature protection
-Communication with stock BMS
-Different regenerative braking and throttle modes
-Weight: 1,3kg
-Features: Mobile App (IOS & Android), stock SurRon display
-Protection class: IP67*
-Regular firmware updates

*While Torp controllers are rated IP67, making them highly water-resistant, the wiring harnesses for both the controller and bike are not waterproof. In case your bike is exposed to water in any way, it is mandatory to apply dielectric grease inside all connectors.

Warranty Policy

Installation manual

Additional information

Weight 2,1 kg
Color

Blue, Black, Red
